Unit type: CS1 Special I/O Units.
Product name: Isolated-type Resistance,
Thermometer Input Units (Ni508.4 Ω).
points Input: 4 inputs.
Signal range selection:
Set separately for each input.
I/O type: INi508.4.
Conversion speed (resolution):
100 ms/4 inputs.
Externa connection: Removable erminal block CS1G-CPU43H.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.15A; 26V, 0 CS1G-CPU43H15A.
Standards: UC1, CE.
Provides the functionality of isolators,
power supplies, signal converters,
and other devices.
The Analog Input Unit converts analog,
input signals such as 1 to 5 V or 4 to 20mA,
into digital values, and takes the values,
scaled in industrial units, and transfers,
it to the CPU Unit as the process value CS1G-CPU43H.
Because of this, no ladder program is required,
at the CPU Unit for scaling.
The Analog Output Unit converts analog output set,
values from the CPU Unit to analog output signals,
such as 4 to 20 mA or 1 to 5 V, and outputs them.
The built-in functions, such as measurement value,
alarms, rate-of-change calculations, and square roots,
have enabled major savings in cost and space compared,
with previous systems CS1G-CPU43H.
High-resolution Models and 8-point Input Models are,
also available.
By combining the Units, logging/monitoring.
systems can be constructed,
or the Units can be used together with LCBs/LCUs,
to construct complete process control systems.
Parameters can be easily displayed and set in an,
easy-to-understand form without special tools. Type: Counter inputs, pulse outputs.
12 DC inputs: Yes.
Counter inputs: 2.
Analog inputs: None.
8 transistor outputs: Yes.
2 pulse outputs: No.
2 analog outputs: Yes.Specifications: Optical ring(GI cable).Specifications: Coaxial cable(5C-2V cable).Specifications: Optical cable(H-PCF cable).Unit type: CS1 CPU Bus Unit.
Product name:EtherNet/IP Unit.
Specifications: Communications,
cable, Shielded twisted-pair(STP),
cable Categories: 100 Ω at 5, 5e;
Communications functions, Tag Data Link,
Functions, Message Communications Functions;
Units per CPU Unit, 8 max.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.41A; 26V, --.
Standards: UC1, N, L, CE.
Introducing the New EtherNet/IP Unit.
More Than 180,000 Words of Tag,
Data Link Capacity!
EtherNet/IP is an industrial multivendor,
network that uses Ethernet.
Managed by the ODVA (Oppen DeviceNet Vendors,
Association), it has open standards and is used,
with a wide range of industrial devices CS1G-CPU43H.
The EtherNet/IP Unit supports tag data links to,
enable sharing data between devices at Ethernet,
nodes and a message sservice for sending and,
receiving data when required CS1G-CPU43H.
The EtherNet/IP Unit supports the same FINS/UDP,
and FINS/TCP functionality as Ethernet Units.
