H7ET-NV1 Self-powered Time Counter
OMRON H7ET-NV1 Manual And Instructions
H7ET-NV1 datasheetPDF datasheet
H7ET-NV1 Communications Manual
OMRON H7ET-NV1 Product information and technical parameters：
Brand: OMRON
Name: Self-powered Time Counter
Model: H7ET-NV1
Timer input: PNP/NPN universal DC voltage input(4.5 to 30 VDC).
Display: 7-segment LCD.
Time range: 999h59min59s ←→ 9999h59.9min(switchable); Light-gray body.
Seven digits, time range 0 to 3999d23.9h.
Dual time range: 999999.9 ←→ 3999d23.9h or,
999h59m59s ←→ 9999h59.9m.
