H7ER-NV1-H Self-powered Tachometer
OMRON H7ER-NV1-H Manual And Instructions
H7ER-NV1-H datasheetPDF datasheet
H7ER-NV1-H Communications Manual
OMRON H7ER-NV1-H Product information and technical parameters：
Brand: OMRON
Name: Self-powered Tachometer
Model: H7ER-NV1-H
Count input: PNP/NPN universal DC voltage input (4.5 to 30 VDC).
Display: 7-segment LCD with backlight.
Max. revolutions displayed (applicable encoder resolution):
1000.0 s–1 (10 pulse/rev.), 1000.0 min–1 (600 pulse/rev.),
←→10000 min–1 (60 pulse/rev.) (switchable). ; Light-gray body.
Revolutions displayed up to five digits.
Dual revolution display according to encoder resolution used;
1000 s–1/1000 min–1 or 1000.0 s–1 /1000.0 min–1,
Switchable dual revolution display type available (-NV1 models);
extended up to 10000 min–1.
