G3FD-X03S-VD DC4-24 Solid State Relays
OMRON G3FD-X03S-VD DC4-24 Manual And Instructions
G3FD-X03S-VD DC4-24 datasheetPDF datasheet
OMRON G3FD-X03S-VD DC4-24 Product information and technical parameters：
Brand: OMRON
Name: Solid State Relays
Model: G3FD-X03S-VD DC4-24
Isolation: Photocoupler.
Zero cross function: --.
Indicator: NO.
Rated output load: 3 A at 4 to 48 VDC (See note 2.).
Rated input voltage: 4 to 24 VDC.
International Standards for G3F Series,
Same Profile as MY Power Relays.
Shape-compatible with mechanical relays.
Certified by UL, CSA, and VDE (model numbers with a suffix of“-VD”).
Socket type, same size as MY Power Relays.
Operation indicator provided to confirm input.
(model numbers with “N” before the suffix).
