E5EN-HTPRR203BF-FLK Programmed temperature controller
OMRON E5EN-HTPRR203BF-FLK Manual And Instructions
E5EN-HTPRR203BF-FLK datasheetPDF datasheet
E5EN-HTPRR203BF-FLK Programmable TypeBasic Type
E5EN-HTPRR203BF-FLK Programmable TypeUser's Manual
E5EN-HTPRR203BF-FLK User's Manual
E5EN-HTPRR203BF-FLK Basic TypeBasic Type
E5EN-HTPRR203BF-FLK User's Manual
E5EN-HTPRR203BF-FLK User's Manual
E5EN-HTPRR203BF-FLK User's Manual
E5EN-HTPRR203BF-FLK Communications FunctionsUser's Manual
E5EN-HTPRR203BF-FLK INSTRUCTION Manual
E5EN-HTPRR203BF-FLK INSTRUCTION Manual
OMRON E5EN-HTPRR203BF-FLK Product information and technical parameters：
Brand: OMRON
Name: Programmed temperature controller
Model: E5EN-HTPRR203BF-FLK
Size: 48 x 96mm.
Category: power AC100 ~ 240V with.
Shell color: black.
Control output 1: position ratio with relay output.
Control output 2: position ratio with relay output.
Control mode: standard or heating cooling.
Auxiliary output points: 2 points.
Heater break, SSR fault detection function: single phase or three phase heater detection function.
Event entry point: 2.
Transfer output: transfer output (special terminal).
Remote SP:4 to 20mA input.
Communication: RS-485.
New program type.
A new type of liquid crystal with high performance cost ratio is adopted in the 256 paragraph,
Visual angle, contrast can be improved.
Can be set up to 8 procedures (mode) x 32 (step) procedure.
High resolution 5 bit display / can display 0.01 degrees C.
High speed sampling period 60ms.
All models complete a variety of (to the thermocouple /Pt/ analog input switching), 1 machines to support a variety of sensors.
Also supports remote SP.
Add PV/SV state display function, to see the state of the thermostat
(automatic / manual, RUN/RESET, alarm), interactive display PV/SV.
Through the support software (Ver.4.3 CX-Thermo) makes the process of setting management becomes very
Simple use of simple computing functions (AND/OR logic and delay) to set the implementation of flexible contact output.
Through the infrared port can be carried out from the front of the communication.
The control output ON/OFF times counting function can predict the fault of the internal relay of the temperature controller.
