E5EC-RR2ASM-009 Digital temperature controller
OMRON E5EC-RR2ASM-009 Manual And Instructions
E5EC-RR2ASM-009 datasheetPDF datasheet
E5EC-RR2ASM-009 RS-485 CompoWay/FUSER'S MANUAL
E5EC-RR2ASM-009 INSTRUCTION Manual
OMRON E5EC-RR2ASM-009 Product information and technical parameters：
Brand: OMRON
Name: Digital temperature controller
Model: E5EC-RR2ASM-009
Size: 48 x 96mm.
Control output 1: relay output.
Control output 2: relay output.
Auxiliary output: 2 independent points.
Power supply voltage: AC100 ~ 240V.
Terminal shape: screw terminal table type.
Input category: full range multi input.
Heating wire break, SSR fault detection function: 2 point (three phase heater).
Communication: RS-485.
Event input: 2 points.
Remote SP input: -.
Transfer output: -.
Large screen display white PV legible. From selection to setting and operation are simple and easy to use.
Full capacity, function and performance of I/O. Suitable for more applications.
E5AC white LCDPV display height is about 25mm.
The upper panel and the front panel are equipped with tool ports.
With the communication conversion line (sold separately) connected to the computer to establish the controller without the need to install the wire for power supply.
Easy to install CX-Thermo (sold separately).
50ms high speed sampling period.
Model can be equipped with up to 4 point auxiliary output, 6 point event input,
1 point transfer output and remote SP input, suitable for a wide range of applications.
The main body is short, the thickness is only 60mm.
Easy to use programmable logic controller (PLC) is connected to the programmable logic controller (PLC).
The temperature controller is connected to each other by using the component communication.
A new type of proportional control allows you to control the valve.
