Field of view: Wide View (Short-distance).
Number of pixels: 350,000 pixels.
Monochrome: NPN.
Field of view/Installation distance: Refer to figure 4 on p.20.
Inspection capabilities, camera options,
and communication options -- this powerful,
heavy weight has it all.
This Vision Sensor provides all of the best-selling,
features found in high-end models without the,
need as in vision system for a separate controller E2EQ Series E2EQ Series
This new Smart Camera was designed to attract,
potential customers to try the FQ2 Series. Appearance: L-shaped.
Sensing method: Through beam (with slot).
Sensing distance: 5 mm (slot width).
Output configuration: Light-ON Dark-ON (2 outputs).
Connection method (Cable length): Pre-wired model with robot cable (1 m) E2EQ Series.
Output type: NPN.
Meeting Customer Needs with.
Ultra-compact Sensors that Mount.
with M3 Screws.
Mount using M3 or M2 screws.
Reliable sensing slot depth of 6.5 mm.
Indication of sensing window for easy confirmation of,
insertion depth.
Bright indicator for confirmation from many directions.
Both light-ON and dark-ON outputs provided E2EQ Series.
All models available with either standard cable or,
flexible robot cable.
Load short-circuit protection circuit provided. Appearance: Horizontal type.
Sensing method: Convergent reflective type.
Sensing distance: 2 to 5 mm.
Output type: NPN output.
Output configuration: Dark-ON.
Accurately detects objects placed in,
front of shiny Background.
A shiny background can be used as long as the distance between,
the sensor and the background is 20 mm or more.
Detects minute objects such as a 0.05-mm-dia. pure copper wire.
Small dispersion in sensing distance.
Light modulation effectively reduces external light interference.
Wide operating voltage range: 5 to 24 VDC. Pressure range: 0 to 200 Pa.
Digital output: NPN open collector.
Lineear output:-- E2EQ Series.
Micropressure Sensor with.
Easy-to-Read Digital Display.
Repeat accuracy of ±1% FS (setting resolution: 0.01 kPa),
high-precision pressure control available.
Compact design (31 × 30 × 30 mm) saves mounting space.
Eassy-to-read red LED indicator E2EQ Series.
Analog current output models available (E8Y-A@Y).
Pressure port Rc (PT) 1/8 models available (-R).
EN and UL approved.
