CJ1W-NCF71 Position Control Unit with MECHATROLINK-II interface
OMRON CJ1W-NCF71 Manual And Instructions
CJ1W-NCF71 datasheetPDF datasheet
CJ1W-NCF71 OPERATION MANUAL
OMRON CJ1W-NCF71 Product information and technical parameters：
Brand: OMRON
Name: Position Control Unit with MECHATROLINK-II interface
Model: CJ1W-NCF71
Unit type: CJ1 CPU Bus Units.
Product Name: Position Control,
Unit with MECHATROLINK-II interface.
Specifications: Control commands,
executed by MECHATROLINK-II,
synchronous communications.
Direct operation by ladder programming.
Control mode: Position control,
speed control or torque control;
No. of axes: 16 axes.
No. of unit numbers allocated: 1.
Current consumption : 5V, 0.36A; 24V,--.
Standards: UC1, CE.
Decrease TCO with Simple Operation,
Reduced Wiring, Batch Settings,
and Batch Management.
Control Servos for up to 16 axes in,
a motion network with one Position,
Control Unit that supports MECHATROLINK-II.
MECHATROLINK-II is a registered trademark,
of the MECHATROLINK Members Association.
