C200HS-CPU21-E CPU
OMRON C200HS-CPU21-E Manual And Instructions
C200HS-CPU21-E SETUP MANUAL
C200HS-CPU21-E SETUP MANUAL
OMRON C200HS-CPU21-E Product information and technical parameters：
Brand: OMRON
Name: CPU
Model: C200HS-CPU21-E
C200HS-CPU21-E CPU
High Performance, Small Rack Style, Built-in RS-232C Port
The C200HS-CPU21-E and C200HS-CPU23-E controllers offer some of the same basic functionality as models C200H-CPU01-E/CPU03-E.
These controllers have the added capabilities ideally suited for high speed machine control,
which includes larger memory,
larger instruction set,
and increased speed.
