Appearance: Knob-type Selector Switch A22W,
LED lighting (without Voltage Reduction Unit).
Number of notches: 2 notches.
Resetting method: Automatic.
Output: SPST-NC + SPST-NC.
Operating voltage: 12 VAC/VDC.
Illumination color: R (red); Y (yellow); G (green); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
Lever for easily mounting and removing the Switch Unit.
Finger protection mechanism on Switch Unit provided as a standard feature EE-1001-1
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type,
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). High performance price ratio standard type proximity sensor.
Standard cable protector.
The new DC two-wire type.
Non polar proximity sensor.
Type: DC three wire / wire type.
Shape: shield, M8.
Detection range: 1.5mm.
Output configuration: NPN.
Action mode: NC. Type: rectangle.
Screen mode: level 2.
Output: SPDT.
Power supply voltage: DC24V.
Contact type: standard load (AC250V, 3A; DC30V, 3A).
Operation: instantaneous action (auto reset).
Operating above color: blue.
Color: red.
In the touch and the ability to protect than OMRON''s previous models have improved.
The micro volume design of 23mm is realized.
Micro design and unique combination of soft sensing.
LED has five colors (red, yellow, green, white, and blue).
Built in basic switch improves touch.
Built in basic switches in the previous model based on the OMRON to improve the protection.
Chip LED to produce a uniform surface brightness.
From the front panel installation, more convenient. Appearance: Shielded, M30.
Sensing distance: 10 mm.
Model: Operation mode, NC.
Proximity Sensor with a Long Screw Length.
Increased tightening strength. Cable protectors,
provided as a standard feature.
Increased indicator visibility.
A milled section for wrench grip on all models. Pressure range: Negative pressure; 0 to -101 kPa.
ON/OFF output: Open collector (two independent outputs).
Linear output: 1 to 5 V.
Model: NPN output.
Pressure Sensor with.
Easy-to-Read LED Display.
Pressure status can be checked at a glance from the,
digital display and bar display.
Measurement pressure prevents incorrect outputs due,
to momentary pressure changes.
Perform automatic teaching simply by teaching pressure,
values for good and bad products.
Industry’s smallest models at just 28 × 28 × 29 mm.
Only in hysteresis mode.
EE-1001-1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=EE-1001-1&select=5
