Appearance: Standard Models, Unshielded 34 dia.
Sensing distance: 25 mm [3 to 25 mm *].
Model: Output configuration, DC 3-wire, NPN;
Operation mode, NC.
Long-distance Capacitive Sensor.
with Adjustable Sensitivity.
CE Marking for DC 3-wire models and AC/DC 2-wire models.
Noise-resistant models are also available for environments with,
strong noise. Cable Specifications: Fire-retardant, Robot cable E2E-X7D2-M1GJ 0.3M
Cable connection direction: L-shaped.
Cable diameter: 6.0 mm dia.
No. of cable cores: 2.
Cable core cross sectional area: 0.5 mm.
Cable length: 5 m.
AC.
Minimum order: 5.
UL-listed: Yes.
Water- and Environment-resistive FA.
Connectors Save Wiring and Maintenance Effort.
Compact FA connectors meet IP67 requirements and ensure a,
94V-0 fire retardant rating.
A wide array of connectors makes a wiring system more modular,
simplifies maintenance, and reduces downtime.
Connectors with Cables and Connector Assemblies are available.
Three types of Connector Assembly: Crimping, soldering, and screw-on.
Connectors with Cables are UL certified.
Based on IEC61076-2-101 (IEC60947-5-2) and NECA 4202. Size: M12 (Brass); Single; Unshielded.
Sensing distance: 20 mm.
Connecting method (See note 1.): M12 Connector.
Body length: Long.
Output configuration: NPN.
Operation mode NC.
A new generation in global applications. Product name: Conductive Level Controller.
Model number: Relay contact (SPST-NO).
Battery (24 VDC) allows use in locations.
without AC power supply. AC sine-wave.
voltage between electrodes enables stable.
detection with no electric corrosion.
Outputs can be set to self-hold at ON or OFF using special circuits.
Adjustable sensitivity, with an operating resistance range of 0 to,
100 kΩ, allows use for a wide variety of liquids.
Relay contact chattering conventionally caused by waves elim,
inated using open collector output, reducing contact wear.
Meets CE marking and is a UL recognized component. Contact type: Microload (125 VAC, 0.1 A; 30 VDC 0.1 A).
Operation: Momentary operation (Self-resetting).
Output: DPDT.
Lighting: LED, 24 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton,
in @. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools.
E2E-X7D2-M1GJ 0.3M Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E2E-X7D2-M1GJ 0.3M&select=5
