Appearance: Shielded, M18.
Sensing distance: 7 mm.
Output configuration: DC 2-wire (polarity).
Operation mode: NO.
Proximity Sensor Ideal for the Food and Beverage Industry. Size: M8, Shielded.
Sensing distance: 2.0 mm.
Connection: M12 connector.
Body material: Stainless steel.
Thread length (overall length): 49 (65).
Output configuration: NPN.
Operation mode NC.
Safe Mounting with Greater
D4B-3570N
Sensing Distance.
Ensures a sensing distance approximately 1.5 to 2,
times larger than that of any conventional OMRON Sensor.
Problems such as the collision of workpieces are eliminated.
Full range of standard sizes (M8, M12, M18 and,
M30; both long and short barrels).
Modular construction simplifies customization. Output: SPDT.
Lighting: LED.
Operating voltage: 12 VAC/VDC.
Pushbutton colorsymbol: R: red, Y: yellow; PY: pure yellow
G: green, A: blue; W: white; B: black *2.
Item: Momentary operation (Self-resetting).
Separate Construction with.
Cylindrical 16-dia. Body.
Miniature design of 28.5 mm, the smallest class in the industry.
Detachable Switch.
The same contacts can be used for both standard loads and microloads.
Easy-to-wire terminal arrangement.
Certified for EN 60947-5-1. Actuator: Roller plunger (Metal roller).
Cable length: 5 m.
Pull-outing direction of cable: Horizontal.
Built-in switch: 1NC/1NO (slow-action).
Smallest Class of Safety Limit Switches the World.
The world''s smallest limit switch with a direct opening,
mechanism (four-contact construction model).
High-sensitivity safety limit switch.
Built-in switches with two- or four-contact construction are available.
Degree of protection: IP67.
Conforms to EN115-1, EN81-1 and EN81-2.
(slow-action models only).
Certified standards: UL, EN (TÜV), and CCC. A closed switch with a built-in standard type switch, with a long service life,
10 million times above the high durability of the micro switch to ensure repeatability.
Small limit switch for Chinese market.
The panel mounting plate is the same as the Z- standard switch.
Compared with the micro switch, it is more suitable for the application of higher mechanical strength, dust proof and anti drop performance.
Resin molding type terminal.
Certified by UL, CSA and CCC (China standard).
D4B-3570N Operation manual/Instructions/Model selection sample download link:
