Input voltage: 400 ~ 500 VAC3 phase.
Rated power: 480W.
Output voltage: 24V.
Output current: 20A.
DIN guide rail installation, with 5 A ~ 40 A output current of the power supply.
3 phase 400 ~ 500 VAC.
5, 10, 20 and 40 A; 24 VDC output.
High stability, low ripple and low noise level.
Compact design.
Add fuse protection.
Natural draft。
In addition to the CE tag, but also in compliance with UL60950 (CSA22 D2F-L202-60950), UL508.
Conform to EN61000-3-2.
Parallel / series operation. Contact type: Standard load (250 VAC, 2 A; 125 VDC 0.4 A).
Operation: Alternate operation (Self-holding).
Output: DPDT.
Lighting: Incandescent lamp, 28 VAC/VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton
n @. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. Type: 1a1b welding terminal.
Shape: square.
Type: General load.
Motor function: alternate action (self retaining).
With lamp: incandescent lamp.
Using voltage: AC/DC24V.
Operation Department color: blue.
20mm long, with 12 round series
High brightness all one side light.
Because it is round, so easy to punch.
Miniaturization, operation feel good. Cable: With cable.
Connector: Connectors on both cable ends.
Cable length L: 1 m.
Minimum order: 5.
Small Round Water-resistive.
Connectors.
Water-resistive, compact connector meets IP67 requirements.
Conventional M8 screw-mounting models are available along with,
S8 snap-in models that connect and disconnect with one touch.
Ideal for a wide variety of FA and OA applications.
Connectors on both cable ends require no harness work.
Some new M8 models with 3 or 5 poles. Free change detection direction.
Detection direction can be according to the front, side (up and down, around 90 units) change.
Can be similar to the feeling of a limit switch installation.
D2F-L20 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=D2F-L20&select=5
