E3F3-R62 detection methods: Regression reflection type,
Wire lead out type,
Type: Plastic appearance; NPN output,
Threaded cylindrical photoelectric sensor, built-in amplifier,
Photoelectric sensor with proximity sensor appearance
High anti interference with optoelectronic -IC technologyCategory: relay output.
Points: 8 points (1a * 8).
Common line processing on the connector side: NPN correspondence (+ public) D2F-L-A1
Rated voltage: DC24V.
Achieve control cabinet miniaturization / save time,
Relay terminal for 8 point output.
Small size of 68 * high 80 * 44mm. (vertical installation)
Total wiring of connector cable.
The common end can be easily connected with the independent contact and the short circuit piece.
The G70D-SOC08 and G70R-SOC08 are connected by a short circuit chip.
When the relay does not need the tool, the relay is convenient to replace the work.
With terminal cover to prevent electric shock.
With action indication LED.
Diode for internal coil surge absorption.
DIN guide rail installation, screw mounting common. Short/disconnection detection: Supported.
Specifications: I/O, PNP (input: - common, output: + common), 16 inputs/16 outputs.
I/O connections: Clamp terminals.
Rated internal circuit power supply voltage:
Supplied from communications connector.
Rated I/O power supply voltage: 24 VDC.
Reduced Wiring and Labor on Factory Sites with Screw-less Terminal Wiring.
Screw-less structure eliminates tightening work.
Detachable terminal blocks for easier maintenance.
Single-step wiring by simply inserting pole terminals. I/O classification: Digital output.
Internal I/O circuit common: PNP (+ common).
I/O points: 16.
I/O connection method: Sensor connector.
Compact Remote I/O Terminals that.
Save Wiring Effort and Enable.
Long-distance Communications.
Long-distance or high-speed communications,
mode is selectable.
Incorporates I/O connectors making it possible to,
minimize the size.
I/O connectors save wiring effort.
Flexible DIN track mounting is possible through a,
DIN track attachment.
Eight-point sensor connector models and 16-point,
MIL connector models are the same size.
D2F-L-A1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=D2F-L-A1&select=5
