Slim and Compact Switch with Better.
Seal and Ensuring Longer Service.
Life than D4E.
Flat springs with an improved lever ratio of the built-in.
switch ensure smooth snap action and long life expectancy.
Protection cover protects the built-in switch from dust and oil.
Plunger incorporates a tough seal cap that lasts for a long time.
One touch connector eliminates need for tedious wiring,
operations and reduces downtime for wiring and,
maintenance (models with standard, easy-to-use screw,
terminals are also available) FZ4-600-10
Minute load model with gold cladding is optimal for,
electronic control.
Molded terminal types as well as molded terminal types,
with operating indicator lamps are available for screw,
terminal systems.
Approved by EN, UL, CSA, and CCC (Chinese standard).
(Ask your OMRON representative for Information on,
approved models.).
No difference in mounting pitch and characteristics,
between D4E-@N and D4E models. Size: 96 x 96mm.
Control output 1: relay output.
Control output 2:--.
Auxiliary output: 2 independent points.
Power supply voltage: AC/DC24V.
Terminal shape: screw terminal table type.
Input category: full range multi input.
Heating wire break, SSR fault detection function: 1 points.
Communication: RS-485.
Event input: 2 points.
Remote SP input: -.
Transfer output: -.
Large screen display white PV legible. From selection to setting and operation are simple and easy to use.
Full capacity, function and performance of I/O. Suitable for more applications.
E5AC white LCDPV display height is about 25mm.
The upper panel and the front panel are equipped with tool ports.
With the communication conversion line (sold separately) connected to the computer to establish the controller without the need to install the wire for power supply.
Easy to install CX-Thermo (sold separately).
50ms high speed sampling period.
Model can be equipped with up to 4 point auxiliary output, 6 point event input,
1 point transfer output and remote SP input, suitable for a wide range of applications.
The main body is short, the thickness is only 60mm.
Easy to use programmable logic controller (PLC) is connected to the programmable logic controller (PLC).
The temperature controller is connected to each other by using the component communication.
A new type of proportional control allows you to control the valve.
FZ4-600-10 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FZ4-600-10&select=5
