Size: M12, Non-shielded.
Sensing distance: 8.0 mm.
Connection: M12 connector.
Body material: Brass.
Thread length (overall length): 34 (48).
Output configuration: PNP.
Operation mode NC.
Safe Mounting with Greater.
Sensing Distance.
Ensures a sensing distance approximately 1.5 to 2,
times larger than that of any conventional OMRON Sensor.
Problems such as the collision of workpieces are eliminated FQ-S25010F
Full range of standard sizes (M8, M12, M18 and,
M30; both long and short barrels).
Modular construction simplifies customization. SYSMAC PLC Units: CQM1-CPU21, CQM1-CPU41, CQM1-CPU42, CQM1-CPU43,
CQM1-CPU44, (Units with RS-232C port), C200HS-CPU31/33/21/23,
CV500/1000/2000-CPU01, CVM1-CPU01/11, CV500-LK201, (Communications port 2),
C200HE-CPU42, C200HG-CPU43/63, C200HX-CPU44/64, C200HW-COM02,
C200HW-COM04, C200HW-COM05, C200HW-COM06, CPM1-CIF01.
Cable length L: 5 m.
Host: Personal computer: IBM PC/AT or compatible.
Ideal Cables for between Programmable Controllers and Host Computers. Item: Sensor Head - Controller Extension Fiber Cable,
(flexible cable) (Fiber Adapter ZW-XFC provided).
Cable length: 30m.
To achieve a compact Sensor Head and high-resolution measurements,
the ZW Series uses a white light confocal principle to detect objects.
This principle is described below. Actuator: Roller lever (stainless steel roller).
Conduit openings: G1/2 (PF1/2).
1NC/1NO (Slow-action).
Robust safety limit switch with metal housing.
Slow-action and snap-action contact with,
certified direct opening operation certification.
Direct opening mechanism (NC contacts only) added to,
enable opening contacts when faults occur, such as fused contacts.
Safety of lever settings ensured using a mechanism that,
engages a gear between the operating position indicator plate and the lever.
Equipped with a mechanism that indicates the applicable,
operating zone, as well as push-button switching to control left and right motion.
Head seal structure strengthened to improve seal properties.
(TÜV: IEC IP67, UL: NEMA 3, 4, 4X, 6P, and 13).
Wide standard operating temperature range: –40 to 80°C (standard type).
Certified standards: UL, CSA, EN (TÜV), and CCC.

FQ-S25010F Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FQ-S25010F&select=5
