Contact type: Microload (125 VAC, 0.1 A; 30 VDC, 0.1 A).
Operation: Momentary operation (Self-resetting).
Case color: Light gray.
Output: DPDT.
Lighting: LED; 24 VDC.
Pushbutton color symbol: R.O.G.W.
Large Square-bodied Lighted.
Pushbutton Switches.
Excellent operating sensitivity.
Excellent illumination with even surface brightness.
Three-color models (green, orange, red; chameleon lighting) ZS-XPT2
included in lineup. Sensing method: Through-beam type (with slot).
Sensing distance: 5 mm (slot width).
Output type: NPN output.
Output configuration: Light-ON.
Photomicrosensor with light,
modulation for reduced external,
light interference and a,
connector for easy maintenance.
Built-in connectors.
Select from four easy-to-use shapes for efficient space,
utilization.
Connectors with locks for safety against vibration.
Convenient mounting method using M3 screws.
Wide operating voltage range: 5 to 24 VDC. Input: Without reset input.
Output: DPDT.
Supply voltage: 100 to 120 VAC, 200 to 240 VAC, 24 VAC/DC, 48 VDC, 100 to 125 VDC.
8-pin models: S-series, M-series.
DIN 48 X 48-mm Power OFF-delay Timer.
Long power OFF-delay times;
S-series: up to 12 seconds,
M-series: up to 12 minutes.
Models with forced-reset input are available.
11-pin and 8-pin models are available. Cable type: Standard Cables.
Type: M12 Connector for Panel Mounting, Front locking.
Cable length: 0.5 m.
Cables and Connectors for,
EtherCAT® and Other Industrial,
Ethernet Networks. Solid-state Timer with Valuable Multiple-time.
Ranges and Multiple-operating Modes.
Handles a wide range of applications through eight operating modes.
With H3BA-N8H models, the output type can be switched.
between time-limit DPDT and time-limit SPDT + instantaneous.
SPDT using a selector.
Setting rings (order separately) to enable consistent settings.
and to limit the setting range.
Panel Covers (order separately) to enable various panel.
designs.
CE marking.
UL, CSA and CCC certification, conforms to LR.
ZS-XPT2 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=ZS-XPT2&select=5
