Number of notches: 2 notches.
Output: SPDT.
Reset method: Manual.
Key release position: Left and right.
Separate Construction with Cylindrical.
16-dia. Body.
Short mounting depth, less than 28.5 mm below panel.
Wide range of switching capacity from standard to microload.
Oil-resistant IP65 models. Contact type: Standard load (250 VAC, 2 A; 125 VDC 0.4 A).
Operation: Alternate operation (Self-holding) CVM1-CLK12
Output: SPDT.
Lighting: LED, 5 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton
n @. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. The ultra small size, high performance and rich models.
5.5mm ultra small built-in amplifier.
Maximum detection distance 2.5mm. Workpiece shaking can also be stable detection.
Response frequency 1kHz.
Low consumption current.
Category: DC 3 wire type.
Shape: non shield.
Detection surface: below.
Detection range: 1.6mm.
Output form: NPN.
Action mode: NO. Size: 48 x 96mm.
Control output 1: relay output (open).
Control output 2: relay output (off).
Auxiliary output: 2.
Communication mode: -.
Heater disconnection: -.
Event input: -.
Plug in terminal: -.
Potentiometer input: there.
Power supply voltage: AC100 ~ 240V.
New highlight LCD panel, font larger, display more clearly integrated low power design,
Longer life performance stability,
Perfect function of proportional valve control special (some models have no potentiometer input virtual opening function)
E5AC-PR-800 white LCDPV display height to reach 25mm, greatly improve the visibility.
The main body is short, and the diameter is only 60mm.
50ms high speed sampling period. Suitable for installation in the 22 panel cutting holes in.
The forced off structure can be contact welding off circuit.
Simply use the swing bar, you can easily install the closed block.
Two switch units are installed in series, which can greatly improve the wiring efficiency.
The switch unit standard finger protection structure.
Easy installation of round or Y type compression connector.
CVM1-CLK12 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=CVM1-CLK12&select=5
