Sensing method: Retro-reflective Sensors.
Appearance: Horizontal.
Connection method: Pre-wired.
Sensing distance: 7 m.
Functions: --.
Model: PNP output.
Ordering Information.
Built-in Amplifier Photoelectric Sensors. Appearance: Shielded, M12.
Sensing distance: 3 mm.
Output configuration: DC 2-wire (1)-(4) pin arrangement.
Operation mode: NO.
Spatter-resistant Fluororesin,
coated Proximity Sensor A6A-10R
Superior spatter resistance.
Long Sensing-distance Models added for sensing,
distances up to 15 mm.
Pre-wired Smartclick Connector Models are also available. Ultra high performance sensors support the core quality of large scale ultra precision measurement.
Measurement center distance of 20 ~ 1500 mm of various models.
Maximum resolution of 0.25 mu m.
Maximum response speed of 110 Mu s.
Support parallel output.
Best size / stability.
Sensor size.
Pay attention to the performance of the best sensor head size and 3 point type fixed structure to ensure superior sensing stability.
Excellent mobile resolution.
Perspective resolution enhancement.
By improving the sensitivity and resolution of the optical lens,
Optimization of optical system,
Thereby greatly reducing the motion resolution error (due to the location of the workpiece surface caused by the error). Number of beams: 51.
Protective height: 1270mm.
Model: PNP output.
Basic Type with a combination of.
performance and functionality.
Up to three sets of series-connected sensors.
The muting function is enabled simply with Muting Key Cap.
Comes standard with interlock and auxiliary output functions. Optical system: positive and negative radiation.
Detection distance: 20 positive and negative 1mm.
Beam shape: linear beam.
Beam diameter: 1.0mm * 20 m.
Resolution: 0.25 M.
Cable length: 0.5m. Appearance: Round/Full-guard type LED lighting,
(without Voltage Reduction Unit) A22L-G.
Output: SPST-NO.
Lighting: LED.
Operating voltage: 6 VAC/VDC.
Operation: Momentary operation (self-resetting).
Illumination color: R (red); Y (yellow); G (green); W (white); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit.
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models).
A6A-10R Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=A6A-10R&select=5
