Appearance: Round/Half-guard type LED lighting,
(without Voltage Reduction Unit) A22L-H.
Output: SPST-NC.
Lighting: LED.
Operating voltage: 24 VAC/VDC.
Operation: Alternate operation (self-holding).
Illumination color: R (red); Y (yellow); G (green); W (white); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit A3DJ-500Y
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). Appearance: Separate type.
Optical system: Through-beam.
Measuring width: 28mm.
Sensing distance: 0 to 500mm.
Resolution: 10µm.
Output type: NPN.
Measurable at any position.
The usual limitations, such as the ''measurement,
area being confined to the center''
or ''large errors due to positioning'',
that used to plague laser measuring sensors,
have now been overcome. Measurements can be,
consistently taken within a 500 mm area,
whatever stage the work is at or whichever way it is inserted.
It can now be set to positions without interference from,
the work feed and without limitations of size of work area. Type: 1a1b welding terminal.
Shape: square.
Type: small load.
Action: instantaneous action (auto recovery).
With light: LED with light.
Using voltage: DC5V.
Operation Department color: red.
20mm long, with 12 round series
High brightness all one side light.
Because it is round, so easy to punch.
Miniaturization, operation feel good. Actuator: Roller lever R38.
Item: Hermetic seal, Molded terminals, -139 models, High-sensitivity.
Pretravel (PT): 10°.
Select the Best Two-circuit Switch for the,
Operating Environment and Application,
from a Wide Range of Models,
A wide selection of models is available, including General-purpose,
Environment-resistant, and Spatter prevention Switches.
Standard-feature gold-clad crossbar contacts provide high reliability.
Applicable to either standard loads or microloads.
Switches with Lever Actuators provide 90° overtravel,
one-side operation, and four-direction head mounting.
Approved standards: EN/IEC, UL, cUL, and CCC.
Contact your OMRON representative for information on approved models.
A3DJ-500Y Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=A3DJ-500Y&select=5
