Classification: Momentary operation.
Shape of Operation Unit: 13 dia.
Output: 1 *1.
Operation Unit color: Green (-G).
Built-in V-series Miniature Basic.
Switch for Compatibility with.
Business and Consumer Equipment.
Momentary operation and lock.
Operation Unit available in six colors.
Improved sense of touch with built-in miniature basic switch. Contact type: Standard load (250 VAC, 2 A; 125 VDC 0
A2A-4A4 A).
Operation: Alternate operation (Self-holding).
Output: DPDT.
Lighting: LED, 24 VDC.
Operation Unit color symbol: Enter the desired color symbol for the,
Pushbutton in @ R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. Model: PY (back-mounting), page 15, PCB terminals.
Number of pins: 11 pins.
A Wide Variety of Square and,
Round Sockets in Front-mounting,
and Back-mounting Models,
Models available with finger protection.
Hold-down Clips and Socket Bridges for PYF Sockets,
are also available.
New screwless models available. Small, easy to use.
Detection mode: on the radio.
Shape: vertical type.
Connection mode: lead wire.
Detection distance: 2 meters of red light.
Output mode: PNP output. Appearance: Round/Projection type LED lighting,
(without Voltage Reduction Unit)A22L-T.
Output: SPST-NC.
Lighting: LED.
Operating voltage: 12 VAC/VDC.
Operation: Momentary operation (self-resetting).
Illumination color: R (red); Y (yellow); G (green); W (white); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit.
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models).
A2A-4A Operation manual/Instructions/Model selection sample download link:
/searchDownload.html?Search=A2A-4A&select=5
