Provincial installation space, vertical 4 point output terminal relay.
28 x 90 x wide high deep into the dimension of the 45mm space saving.
Equipped with built-in G6D relay type and non contact G3DZ power FET MOS relay type, complete varieties.
The terminal is IN/OUT separate structure, so it is convenient for wiring.
LED with action indication.
Diode for internal coil surge absorption.
Using a special socket, the relay can be replaced conveniently MY4N DC24
DIN guide rail installation, screw mounting common.
Disassembly tool with relay. Size: 6 dia.
Type: Low measurement type.
Sensing distance: 4 mm.
Resolution (See note.): 0.1 μm.
For the most recent information on models that have been,
certified for safety standards, refer to your OMRON website. Shape: socket (with open end cap).
Pole number: 20.
Pole pole number: 1.
Minimum packing unit: 100.
Printed board connector core, MIL specification standard.
Through the use of new productivity design, high reliability and low price synchronization.
A box type plug (XG4C) which is convenient for saving space is provided in the province.
A press type plug (XG4E) capable of using the relay is provided.
Will be the company''s loose wire connector (XG5) - specific plug (XG8) and PCB type.
(XG2) combined use of various types of packaging can be achieved.
Suitable for the company''s own development of a simple locking lever can make the unique plug (XG8) and,
Box type plugs (XG4C) can also be locked.
MIL specification (MIL-C-83503) standard.
Standard product conforms to the UL specification (No. E103202 File) certified products. Appearance: Shielded, M30.
Sensing distance: 12 mm.
Output configuration: DC 2-wire (no polarity) .
Operation mode: NO.
Proximity Sensor Ideal for the Food and Beverage Industry. Size: 48 x 96mm.
Control output 1: relay output (open).
Control output 2: relay output (off).
Auxiliary output: -.
Communication mode: -.
Heater disconnection: -.
Event input: -.
Plug in terminal.
Potentiometer input: there.
Power supply voltage: AC100 ~ 240V.
New highlight LCD panel, font larger, display more clearly integrated low power design,
Longer life performance stability,
Perfect function of proportional valve control special (some models have no potentiometer input virtual opening function)
E5AC-PR-800 white LCDPV display height to reach 25mm, greatly improve the visibility.
The main body is short, and the diameter is only 60mm.
50ms high speed sampling period.
