Time specification: Instantaneous type.
Current setting range: 8 to 26 A.
Operating voltage: 100/110/120 VAC.
Resetting method: Automatic (See note.).
Solid-state Relay Enables Choice of Three.
Operating Functions (Overcurrent, Open,
phase, and Reverse-phase).
Protects 3-phase induction motors and their loads from damage.
Selection and combination of operating functions from overcur,
rent, open-phase, and reverse-phase MSF4800B-40-1080
Circuit and output relay operation can be checked by just operat,
ing the test button.
The set time value can be checked easily because operation time,
is indicated from the start of operation.
Space-saving, integrated construction.
Note: If the K2CM is used with an inverter, the operating conditions will,
depend on the load wiring length, inverter carrier frequency, basic,
frequency, and load conditions. Error will occur in the operating,
values of the overload elements. It is recommended to test operation,
before using the K2CM. Category: snap in type (pre installed).
Character height: decimal: 4.8mm, sixteen hex: 3.2mm.
Terminal: welding terminal.
Terminal color: light gray.
Output code number: 19 (decimal code, with parts to increase the provisions).
Locked in series.
Character height 4.8 or 3.2mm to make the display easy to view.
Installing the card into the installation makes it easy to install.
This series includes all lock type to prevent accidental operation. Ratings: 0.1 A.
Actuator: Long hinge lever.
Terminals: Molded lead wires (300 mm).
Contact form: SPDT.
Sealed Miniature Basic.
Switch Conforms to IP67.
(Excluding the terminals on terminal models).
Use of epoxy resin assures stable sealing, making.
this switch ideal for places subject to water spray.
or excessive dust.
V-series internal mechanism assures high.
precision and durability. The mounting is the,
same as of the V models.
Ideal for automobiles, agricultural machines,
large-scale home appliances, and industrial,
equipment, which require high environmental resistance.
MSF4800B-40-1080 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=MSF4800B-40-1080&select=5
