Category: relay output.
Points: 8 points (1a * 8).
Common line processing on the connector side: corresponding (+ public).
Rated voltage: DC24V.
To achieve the control cabinet of miniaturization / save time,
Relay terminal for 8 point output.
Small size of 136 * high 80 * 55mm. (vertical installation)
The total wiring of the connector cable is realized.
The common end can be easily connected with the independent contact and the short circuit piece M2CA-90A1-06W
The G70D-SOC08 and G70R-SOC08 are connected by a short circuit chip.
When the relay does not need the tool, the relay is convenient to replace the work.
With terminal cover to prevent electric shock.
Diode for internal coil surge absorption.
DIN guide rail installation, screw mounting common. Case color: Black.
Control output: Voltage output (for driving SSR).
Control mode *1: Standard or heating/cooling.
No. of auxiliary outputs: 1.
Detection of heater burnout, SSR failure, and heater overcurrent: --.
No. of event inputs: 2.
Transfer output *2: --.
Communi cations: --.
Previous model: Thermocouple input, --;
Resistance thermometer input, --.
New 48 x 24-mm Basic Temperature,
Controller with Enhanced Functions and,
Performance. Improved Indication Accuracy,
and Preventive Maintenance Function.
Indication Accuracy.
Thermocouple input: ±0.3% of PV (previous models: ±0.5%),
Pt input: ±0.2% of PV (previous models: ±0.5%),
Analog input: ±0.2% FS (previous models: ±0.5%),
Models are available with screw terminal blocks or screwless,
clamp terminal blocks.
A PV/SV-status display function can be set to automatically alternate,
between displaying the status of the Temperature Controller (auto/
manual, RUN/STOP, and alarms) and the PV or SV.
Preventive maintenance for relays in the Temperature,
Controller using a Control Output ON/OFF Counter.
Switch the PV display between three colors.
Compatible with Support Software (CX-Thermo version 4.2 or higher).
Eleven-segment displays.
Models are available with one or two alarm outputs.
M2CA-90A1-06W Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=M2CA-90A1-06W&select=5
