Name: Compact Connectors.
Specifications: Inputs/Outputs; 2 input/2 output; PNP.
Bit slave of smallest class in industry,
Innovation in wiring for any type of machinery.
Available in 2 types: 2-point Bit Slave Unit,
and 4-point Bit Slave Unit.
Compact size for installation in limited space.
Save space and wiring since bit slave can be,
installed near I/O devices.
Industry first bit slave connectable with round,
cables which can be easily purchased at a lower price K8DS-PZ2
Connectable with flat cables, too for easy wiring.
Cables are selectable depending on applications. Name: Three-tier Screw Terminal Block.
Specifications: Inputs; 8 inputs; PNP;
With Short-circuit and,
Disconnected Line Detection.
"Easy" and "Flexible" system expansion,
with linked CC-Link and CompoNet.
Branching is easily made with CompoNet.
Wiring material cost can be reduced.
Bit-level I/O distribution reduces,
wiring in the system.
A wide variety of CompoNet Slave Units,
contribute to system size reduction.
Seven-segment Display on the Gateway Unit,
helps to detect errors on site.
The Participation Flags and Communications,
Error Flags can be checked at the Host,
Controller to detect the location and,
content of the error. Contact type: Standard load (250 VAC, 2 A; 125 VDC 0.4 A).
Operation: Momentary operation (Self-resetting).
Output: SPDT.
Lighting: LED, 24 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton
n @. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. Type: Wide View.
Working length: 38 to 194 mm (variable).
Sensing area: 10 × 9.2 mm (H × V) to 50 × 46 mm (H × V).
Low-cost but advanced Smart.
Sensors combining benefits of.
optical and vision sensors.
Sensor integrated with light for easy installation.
Easy operation by selecting icons while watching.
LCD monitor.
Ultra-high speed response for fast-moving.
production lines.
K8DS-PZ2 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=K8DS-PZ2&select=5
