Type: rectangle.
Screen mode: level 2.
Output: DPDT.
Power supply voltage: DC24V.
Contact type: standard load (AC250V, 3A; DC30V, 3A).
Operation: alternating action (self retaining).
Operating above color: red.
Color: blue.
In the touch and the ability to protect than OMRON''s previous models have improved.
The micro volume design of 23mm is realized.
Micro design and unique combination of soft sensing K2ZC-K2DS-N
LED has five colors (red, yellow, green, white, and blue).
Built in basic switch improves touch.
Built in basic switches in the previous model based on the OMRON to improve the protection.
Chip LED to produce a uniform surface brightness.
From the front panel installation, more convenient. Contact type: Microload (125 VAC, 0.1 A; 30 VDC 0.1 A).
Operation: Momentary operation (Self-resetting).
Output: SPDT.
Lighting: Incandescent lamp, 28 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton,
in @@. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. Size: M12 (brass), single distance, shielding type.
Detection range: 2mm.
Connection mode: lead type (cable length is 2M and 5m two).
Thread length: Standard type.
Output type: PNP.
Action mode NC.
Set up the new standard of the world economy proximity sensor.
OMRON as a pioneer and leader in proximity sensor industry,
Now bring you a new E2B proximity sensor with high performance to price ratio.
This series of products are complete,
Aimed at reasonable prices to meet customer demand for high quality and high reliability of the sensor.
We have tested the product not only on the protection level (IP67) specific item,
The oil spray test was carried out on the condition of the work site.
Simulation test was carried out in the environment of high oil mist concentration. Fitting materials: Stainless steel (SUS304).
Count: 1.
Accessories: Description, Holder (upper) Holder,
(lower) Pipe Bolts M4 × 12 with Hexagonal holes,
Bolts M4 × 30 with hexagonal holes,
Phillips screws M3 × 12 (with spring and plain washers),
Spring washer M4 Plain washer M4 Nuts M4;
Material, Heat-resistant ABS resin, 66 nylon,
Stainless steel (SUS304), Iron, nickel plating,
Iron, nickel plating, Stainless steel (SUS304),
Iron, nickel plating, Iron, nickel plating,
Iron, nickel plating; Count, 1, 1, 1, 2, 1, 2, 1, 1, 3.
Applicable sensor (mounting pitch on sensor side): E3Z (25.4) E39-R1/E39-R3.
Page: Dimensions, 9.
K2ZC-K2DS-N Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=K2ZC-K2DS-N&select=5
