Appearance: Round/Half-guard type LED lighting,
(without Voltage Reduction Unit) A22L-H.
Output: SPST-NC.
Lighting: LED.
Operating voltage: 24 VAC/VDC.
Operation: Alternate operation (self-holding).
Illumination color: R (red); Y (yellow); G (green); W (white); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit XS2F-M12PVC3A2M
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). Type: Long-distance (for 2 km).
G1 models.
Compact, Space-saving Plug-in Type Ideal,
for Pump Panels or Building into Equipment.
Large switching capacity: 5 A at 220 VAC (resistive load).
Easy to handle with DIN rail mounting.
Replace for maintenance without rewiring the socket. Rated voltage: 100 V.
Permitted voltage fluctuation range: 85% to 110% rated voltage.
Frequency: 50/60 Hz.
Rated rotational speed: 50 Hz, 2300 r/min; 60 Hz, 2600 r/min.
Maximum flow rate: 50 Hz, 1.6 m3/min; 60 Hz, 1.9 m3/min.
Maximum static pressure: 50 Hz, 41 Pa; 60 Hz, 43 Pa.
Noise: 50 Hz, 44 dB; 60 Hz, 47 dB.
Weight: Approx. 2260 g.
Comprehensive Lineup of Single,
Double, and Triple Axial Fans with,
Easy One-step Mounting.
Mounts in a square cutout and conceals the hole-cut to,
simplify installation work.
Cover can be set to open either upward or downward for,
convenience in confined spaces.
Enhanced accessories (finger guard, filter, plug cord,
mounting screws).
Optional Replacement Filter and Vent Attachment.
The lineup includes Single, Double, and Triple Box Fans,
with eight models with plastic blades and eight models with,
metal blades. Applicable CPU Units: CQM1H-CPU51/61.
Connection location and number of Units: One Unit only.The Unit must be connected between the Power Supply Unit and the CPU Unit.
Dimensions: 25 × 110 × 107 mm (W × H × D).
Weight: 170 g max.
XS2F-M12PVC3A2M Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=XS2F-M12PVC3A2M&select=5
