Appearance: Round/Projection type A22-T.
Output: SPST-NO + SPST-NO.
Operation: Alternate operation (self-holding).
Illumination color: R (red); Y (yellow); G (green);
W (white); A (blue); B (black).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit.
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature
XG4M-1630-U
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). High-precision Switch for Detecting Micron-unit,
Displacement.
Ideal for detecting and measuring wear of cutting,
tools or for original point of work.
Ceramic plungers on M5, M8, and slim models for,
superior abrasion resistance and resistance to,
temperature changes.
Direct input possible to microprocessors and,
programmable controllers.
A version with screw-type cable connector available,
for easy installation and maintenance. Number of beams: 15.
Protective height: 720mm.
Model: PNP output.
Basic Type with a combination of.
performance and functionality.
Up to three sets of series-connected sensors.
The muting function is enabled simply with Muting Key Cap.
Comes standard with interlock and auxiliary output functions. C200H-CPU31-E CPU
High-Performance CIM Version
The C200H-CPU31-E controller offers a high-performance CPU especially designed for computer integrated manufacturing environments.
The C200H-CPU31-E has all the capabilities of C200H C200H CPU21/CPU23,
with clock/calendar as a standard feature.This CPU is used in either SYSMAC NET and/or SYSMAC LINK communicationAdvanced Functionality in a Super Compact Design.
Compact AC Servo Drives.
The footprint of the compact AC Servo Drives is only 48%,
that of the SMARTSTEP A Series, and the volume is only,
39%. The AC Servo Drives of the SMARTSTEP 2 Series,
are also equipped with new functions and higher perfor,
mance for more accurate positioning.
Vibration Suppressed during Acceleration/Deceleration of,
Low-rigidity Mechanisms.
Damping control suppresses vibration when using the,
SMARTSTEP 2 for low-rigidity mechanisms or devices in,
which the end vibrates.
Resonance Control for High-speed Positioning.
Realtime autotuning estimates the load inertia of the ma,
chine in realtime and automatically and constantly sets the,
optimal gain. The adaptive filter automatically suppresses,
vibration caused by resonance.
Compatible with 90° Phase Difference Input Command,
Pulses.
In addition to conventional CW/CCW inputs (2 pulses) and,
SIGN/PULS inputs (1 pulse), the SMARTSTEP 2 supports,
90° phase difference inputs. This makes it possible to input,
encoder output signals directly into the Servo Drive for sim,
plified synchronization control.
XG4M-1630-U Operation manual/Instructions/Model selection sample download link:
/searchDownload.html?Search=XG4M-1630-U&select=5
