Contact type: Microload (125 VAC, 0.1 A; 30 VDC 0.1 A).
Operation: Momentary operation (Self-resetting).
Output: DPDT.
Lighting: LED, 24 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton
n @. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation WCAG-N 4M
Easy panel mounting from the front and simple lamp replacement.
without tools. Terminal/mounting: Plug-in/DIN rail via socket.
Control voltage: 24 VDC.
Overcurrent detection: Instantaneous type, W/o start-up lock.
Solid-state, Plug-in Current Sensor.
Applicable to motor overcurrent protection and 3-phase AC current detection.
Inverse-type, start-up lock type, and instantaneous type over,
current sensors available.
Instantaneous type under current sensor available.
Plug-in design simplifies installation, removal, and wiring.
DIN sized (48 mm x 96 mm). Model: A7BS.
Classification (See note 1.): Snap-in (front mounting).
Character height: Decimal: 4.8 mm Hexadecimal: 3.2 mm.
Terminals: Solder terminals *1.
Color: Light gray.
Output code number: 07 (binary coded decimal, with component adding provision) *3.
Wide Range of Locking-type.
Models Available.
Character height of 4.8 or 3.2 mm makes for easy-to,
view display.
Installation is easy with snap-in mounting.
The series includes a complete range of locking-type,
models that prevent accidental operation. Output: DPDT.
Lighting: LED.
Operating voltage: 24 VAC/VDC.
Pushbutton colorsymbol: R: red, Y: yellow; PY: pure yellow
G: green, A: blue; PW: pure white; B: black *2.
Item: Alternate operation (Self-holding).
Separate Construction with.
Cylindrical 16-dia. Body.
Miniature design of 28.5 mm, the smallest class in the industry.
Detachable Switch.
The same contacts can be used for both standard loads and microloads.
Easy-to-wire terminal arrangement.
Certified for EN 60947-5-1. Appearance: Shielded, M12.
Sensing distance: 4 mm.
Output: NPN.
Model: Operation mode NC.
Aluminum and Iron Both.
Detectable from Long Distances.
WCAG-N 4M Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=WCAG-N 4M&select=5
