Classification: Models with built-in operation indicators.
Rated voltage: Standard products, 100/110 or 200/220 VAC, 24 VDC;
Made-to-order items, 12, 24, 100/120, or 200/240 VAC, 12, 48, or 100/110 VDC.
New Latching Levers for Circuit Checking.
Added to Our Best-selling.
MY General-purpose Relays.
Now lead-free to protect the environment.
VDE certification (Germany).
Different colors of coil tape for AC and,
DC models to more easily distinguish them TL-W5F1
MY(S) models with latching levers added for,
easier circuit checking. Product name: NV3W-V1.
Specifications: Screen size, 3.8-in, STN monochrome; Number of dot, 240 × 96 dots;
Communications, RS-232C; Power supply voltage, 24 VDC;
Backlight, LEDs, 3 colors (green, orange, and red).
Compact and Simple, Extremely.
High Cost Performance.
The lineup includes compact and horizontal models from.
3.8-inch to 4.6-inch and QVGA models.
Trur Type Fonts for Flexible Screen Designs.
Space-saving Installation.
Multi-language Support and Safety Standard Compliance. Sensing method: Reflective model(for mark detection).
Connection method: Pre-wired (2 m).
Sensing distance: 30±5 mm.
Extremely thin beam ideal for detection of minute objects and marks.
Ideal for detection of small objects and slight color differences.
Bad mark detection.
Detection of thin wire of 200 μ.
Detection of slight level differences. Size: 48 * 48mm, terminal type.
Category: control output 1 point type (power supply AC100 ~ 240V).
Shell color: black.
Control output: linear voltage output.
Control mode: standard or heating cooling.
Auxiliary output points: 2 points.
Heater break, SSR fault detection function: -.
Event entry point: 2.
Transfer output: output (special terminal).
Communication: -.
New program type.
A new type of liquid crystal with high performance cost ratio is adopted in the 256 paragraph,
Visual angle, contrast can be improved.
Can be set up to 8 procedures (mode) x 32 (step) procedure.
High resolution 5 bit display / can display 0.01 degrees C (to achieve a small size of 48 x 48mm).
High speed sampling period 60ms.
Full of all models (capable of thermocouple /Pt/ analog input switching),
1 machines to support a variety of sensors.
Add PV/SV state display function, to see the state of the thermostat
(automatic / manual, RUN/RESET, alarm),
Interactive display PV/SV.
By supporting software (Ver.4.3 CX-Thermo),
In simple arithmetic functions (AND/OR logic and delay).
Setting the program settings that can perform flexible contact output.
The control output ON/OFF times counting function can predict the fault of the internal relay of the temperature controller.
TL-W5F1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=TL-W5F1&select=5
