Contact type: Microload (125 VAC, 0.1 A; 30 VDC, 0.1 A).
Operation: Momentary operation (Self-resetting).
Case color: Black.
Output: SPDT.
Lighting: Incandescent lamp; 28 VDC/VAC .
Pushbutton color symbol: R.O.G.W.
Large Square-bodied Lighted.
Pushbutton Switches.
Excellent operating sensitivity.
Excellent illumination with even surface brightness.
Three-color models (green, orange, red; chameleon lighting) SAO-SU5N
included in lineup. Number of beams: 36.
Protective height: 1080mm.
Safety Light Curtains with Durable,
Impact-resistant Body and Long,
20-m Sensing Distance.
MS/MSF4800A Advanced Series.
Programming and Diagnostics Module (PDM) makes it easy,
to set functions.
Series connection is possible only with the MSF4800A.
Blanking can be set.
Muting is possible only with the MSF4800A by using the,
MS4800-RM6 Resource Module.
MS/MSF4800B Basic Series,
Features all necessary basic Safety Light Curtain functions.
Series connection is possible only with the MSF4800B.
Programming and Diagnostics Module (PDM) makes it easy,
to set functions. Model: A7BS.
Classification (See note 1.): Snap-in (front mounting), With external stoppers.
Character height: Decimal: 4.8 mm.
Terminals: Solder terminals *1.
Color: Light gray.
Output code number: 07 (binary coded decimal,
with component adding provision) *3.
Wide Range of Locking-type.
Models Available.
Character height of 4.8 or 3.2 mm makes for easy-to,
view display.
Installation is easy with snap-in mounting.
The series includes a complete range of locking-type,
models that prevent accidental operation. Actuator: Roller lever: R38.
Indicator: LED.
Item: High-sensitivity.
Pretravel (PT): 10°.
Select the Best Two-circuit Switch for the,
Operating Environment and Application,
from a Wide Range of Models,
A wide selection of models is available, including General-purpose,
Environment-resistant, and Spatter prevention Switches.
Standard-feature gold-clad crossbar contacts provide high reliability.
Applicable to either standard loads or microloads.
Switches with Lever Actuators provide 90° overtravel,
one-side operation, and four-direction head mounting.
Approved standards: EN/IEC, UL, cUL, and CCC.
Contact your OMRON representative for information on approved models.
SAO-SU5N Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SAO-SU5N&select=5
