Appearance: Knob-type Selector Switch A22W,
LED voltage-reduction lighting (without Voltage Reduction Unit).
Number of notches: 2 notches.
Resetting method: Manual.
Output: SPST-NO + SPST-NO.
Operating voltage: 100 VAC.
Illumination color: R (red); Y (yellow); G (green); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
Lever for easily mounting and removing the Switch Unit.
Finger protection mechanism on Switch Unit provided as a standard feature S8JC-ZS10012CD-AC2
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type,
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). Easy on-site input on-the-move.
Incorporation of plastic rod actuator makes the Switch easy on hands.
One-way operation:
Equipped with stopper so that operation is only possible from one direction.
Distinctive yellow used for the body.
Three different types of mounting are available.
Models with emergency-stop switch are available to suit the application. Shape: tension release (XG4M).
Pole number: 34.
Pole pole number: 1.
Minimum packing unit: 200.
Printed board connector core, MIL specification standard.
Through the use of new productivity design, high reliability and low price synchronization.
A box type plug (XG4C) which is convenient for saving space is provided in the province.
A press type plug (XG4E) capable of using the relay is provided.
Will be the company''s loose wire connector (XG5) - specific plug (XG8) and PCB type.
(XG2) combined use of various types of packaging can be achieved.
Suitable for the company''s own development of a simple locking lever can make the unique plug (XG8) and,
Box type plugs (XG4C) can also be locked.
MIL specification (MIL-C-83503) standard.
Standard product conforms to the UL specification (No. E103202 File) certified products. Model: CPM2A-30CDT1-D. Power supply: DC power supply.
Output type: Transistor sourcing.
Inputs points: 18 points.
Outputs points: 12 points.
S8JC-ZS10012CD-AC2 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=S8JC-ZS10012CD-AC2&select=5
