Product name: CJ2M (Built-inEtherNet/IP) CPU Units.
Specifications: I/O capacity/Mountable Units(Expansion Racks),
2, 560 points/40 Units(3 ExpansionRacks max. );Programcapacity,
60K steps;Data memorycapacity, 160K words,
(DM: 32K words, EM: 32K words ×4 banks);
LD nstruction execution time, 0 CQM1-TC002.04 μs;
EtherNet/IP function: YES;
Option board slot: YES..
Current consumption (A): 5V, 0.7(See note. );24V, --.
Standards: UC1, N, L, CE.
CJ2M for basic machine automation CQM1-TC002.
The CJ2M Series is ideal for packaging and general.
machine automation needs. Connectivity is assured.
thanks to the built-in USB port and the choice of.
Ethernet and RS-232C/422/485 interfaces on the CPU. Unit type: CS1 Special I/O Units.
Name: CompoBus/S Master Unit CQM1-TC002.
Specifications: Communications,
functions, Remote I/O communications;
No. of I/O points, 256 max.
(128 inputs and 128 outputs), 128 max.
(64 inputs and 64 outputs);
Max. Units mountable per CPU Unit, 95, 96.
No. of unit numbers allocated: 2; 1 OMRON CQM1-TC002.
Current consumption: 5V, 0.15A; 26V, --.
Standards: U, C, CE.
CompoBus/S is a high-speed I/O bus.
Specification: Thermocouple input (J/K),
ON/OFF or advanced PID control,
transistor (PNP) output, 2 loops.Unit type: CJ1 Special I/O Units.
Product name: Analog Input Unit OMRON CQM1-TC002.
I/O points: 4 inputs;
Signal range selection: 1 to 5 V, 0 to 5 V,
0 to 10 V, -10 to 10 V, 4 to 20mA;
1/4,000(Settable to 1/8,000)*2 .
Conversion period: 1 ms/point,
(250 μs/point can also be set.)*2.
Accuracy at ambient temperature of 25°C:
Voltage: ±0 OMRON CQM1-TC002.2% of F. S. Current: ±0.4% of F.S.
External connection: Removable terminal block.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.42A; 24V, --.
Standards: UC1, N, L, CE.
Consistent Microsecond Throughput:
Models with Direct Conversion Join the Lineup.
Analog Input Units for converting analog input,
signals into binary data.
Analog Output Units for converting binary ,
data into analog output signals. Model : CVM1-PRS21-V2.
For ladder.Unit type: CJ1 Basic I/O Units.
Product name: Transistor Output Units.
Specifications: Output type, Sinking;
I/O points, 32 outputs;
Maximum switching capacity, 12 to 24VDC, 0.5A;
Commons, 16 points, 1 common;
External connection, Fujitsu connector.
No. of words allocated: 2 words.
Current consumption: 5V, 0.14A; 24V, --.
Standards: UC1, N, L, CE.
A Wide Range of Basic Output,
Units for High Speed Output,
and Different Applications.
These Outpuut Units receive the ,
results of output instructions ,
from the CPU Unit and perform ON/OFF,
control for external devices CQM1-TC002.
High-speed Output models CJ1W-OD213 and,
CJ1W-OD234 can help to increase system.
throughput.
